| 精度定格: | P0 | 行数: | 単一行 |
|---|---|---|---|
| 材料: | GCR15 | 内径: | 40～60ミリ |
| 外径: | 68-95 mm | 幅: | 15〜18mm |
| 重さ: | 0.25-0.5 kg | 構造: | 深い溝 |
| タイプ: | ボール | ボアサイズ: | 40 - 60のmm |
| 密封器の種類: | 密閉 | 動的負荷: | 16-25.3 kn |
| 静的負荷: | 20.6-35.1 kn | 最大速度: | 1800-3500 MIN-1 |
| 引力 トルク: | 15-25 ncm | ||
| ハイライト: | 40mm one way clutch bearing sealed,60mm one way clutch bearing,sealed one way clutch bearing |
||
| Attribute | Value |
|---|---|
| Applicable Industries | Machinery Repair Shops, Food & Beverage Factory, Energy & Mining |
| Precision Rating | P0 |
| Number of Row | Single row |
| Material | Gcr15 |
| Inner diameter | 40-60 mm |
| Outer diameter | 68-95 mm |
| Width | 15-18 mm |
| Weight | 0.25-0.5 kg |
| Package | Cartons Paper Box |
| Port | Shanghai; Ningbo |
| Delivery time | Prompt |
| Application | Machinery |
| Structure | Deep Groove |
| Type | BALL |
| Bore Size | 40 - 60 mm |
| Seals Type | Sealed |
| Type | Size | Bearing Series | TKN1 (Nm) | nmax (min-1) | Outside Diameter (mm) | Height (mm) | Bearing loads Dynamic (kN) | Bearing loads Static (kN) | Weight (kg) | Drag torque (Ncm) |
|---|---|---|---|---|---|---|---|---|---|---|
| ASK | 40 | 6008 | 72 | 3500 | 68 | 15 | 16 | 20.6 | 0.25 | 15 |
| ASK | 50 | 6010 | 125 | 2200 | 80 | 16 | 19.6 | 23.5 | 0.34 | 20 |
| ASK | 60 | 6012 | 250 | 1800 | 95 | 18 | 25.3 | 35.1 | 0.5 | 25 |
